| Place of Origin: | CHINA |
|---|---|
| Brand Name: | FORZATEC |
| Certification: | CE ROHS |
| Model Number: | FT-LMO-12-10 |
| Minimum Order Quantity: | 200 PCS |
| Packaging Details: | CARTON AND PALLETS |
| Delivery Time: | 15 DAYS UPON ORDER |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 packs per month |
| Type: | LMO | Connection Mode: | Series And Parallel |
|---|---|---|---|
| Nominal Voltage: | 11.1V | Nominal Capacity: | ≥10Ah (Test Condition @ 0.3C, 25°C) |
| Charge Cut-off Voltage: | 12.6V | Discharge Cut-off Voltage: | 8.4V |
| High Light: | lmo lithium ion battery,large capacity lithium ion battery |
||
12V10Ah LMO Lithium Ion Battery Solar Street Light Power Storage
12V10Ah LMO liithium battery is a fine potential replacement for outdoor solar PV garden light power storage, which makes the lifespan of the light system doubled and saves the space and installation work of the storage. The battery can be easily installed under the Solar Panel or on the light pole with a couple of nuts and bolts. 12V platform is the most common DC power worldwide for modern energy-saving LED light. FORZATEC configure the 12V LMO battery packs by 3 series of 3.6/3.7V LMO cells with fully charged voltage 4.2V/4.3V and PCB with optimized dimensions and sufficient electrical performances as the users require. The battery pack working voltage range 9V-12.6V matches the LED light perfectly during its actual routine illumination.
| Capacity |
Rated Capacity :10Ah
|
||||||||||||||||||||||||||||
| Rated Voltage | 12V | ||||||||||||||||||||||||||||
| Internal Resistant | ≤60mΩ | ||||||||||||||||||||||||||||
| Discharge End Voltage | 9V | ||||||||||||||||||||||||||||
| Charge Upper Limit Voltage | 12.6±0.2V | ||||||||||||||||||||||||||||
| Standard Charge Circuit | 5 A | ||||||||||||||||||||||||||||
| Fast Charge Circuit | 10 A | ||||||||||||||||||||||||||||
|
Standard Discharge Circuit |
5 A | ||||||||||||||||||||||||||||
| Fast Discharge Circuit | 10A | ||||||||||||||||||||||||||||
| Discharge Circuit (max) | 15A | ||||||||||||||||||||||||||||
| Weight1 | 1.3kg±0.1kg | ||||||||||||||||||||||||||||
| Dimension(max) |
Length : 60mm Width : 150mm Height : 90mm
|
||||||||||||||||||||||||||||
| Operational Temperature |
charge :0 ~ 45℃; discharge :-20 ~ 60℃ |
||||||||||||||||||||||||||||
| Storage Temperature |
within a month : -5 ~ 35℃ within six months : 0 ~ 35℃ 12V10Ah NMC liithium battery is a fine potential replacement for outdoor solar PV garden light power storage, which makes the lifespan of the light system doubled and saves the space and installation work of the storage. The battery can be easily installed under the Solar Panel or on the light pole with a couple of nuts and bolts. 12V platform is the most common DC power worldwide for modern energy-saving LED light. FORZATEC configure the 12V LMO battery packs by 3 series of 3.6/3.7V NMC cells with fully charged voltage 4.2V/4.3V and PCB with optimized dimensions and sufficient electrical performances as the users require. The battery pack working voltage range 9V-12.6V matches the LED light perfectly during its actual routine illumination.
|
