| Place of Origin: | China |
|---|---|
| Brand Name: | FORZATEC |
| Certification: | CE ROHS |
| Model Number: | FT-LFP-12-20 |
| Minimum Order Quantity: | 100 |
| Packaging Details: | Carton + Pallet |
| Delivery Time: | 15 |
| Supply Ability: | 10000 |
| Battery Type: | Lifepo4 | Nominal Voltage: | 12.8V |
|---|---|---|---|
| Nominal Capacity: | ≥20Ah (Test Condition @ 0.3C, 25°C) | Charge Cut-off Voltage: | 14.6V |
| Battery Packing: | Aluminum Box | ||
| High Light: | lifepo4 lithium battery,lifepo4 rechargeable battery |
||
12V20Ah LiFePO4 Lithium Battery
12V20Ah Lifepo4 Lithium Battery works as an ideal ESS unit for solar autonomous light for its mini size, safe performance, deep depth of discharge, and long cycle life upto to 2,000. FORZATEC Lfp Battery packs are also famous and applicable for the convenience for installation and water resistance, which greatly cut down on the cost of maintanence and after sale service. 12V20Ah LFP battery can be configured by 32700 LiFePO4 cylindrical cells, pouch cell, and cubic (prismatic) cell. The electric specification can be customerized based on specific requirements from every corner of the installation sites.
12V voltage platform is the most widely applied DC power worldwide for electric tools, solar PV light, emergency light, mine lights, aircraft model, electric toy, power storage, portable power bank, e-bike, etc. FORZATEC configures the 12V battery packs by 4 series of 3.2V LiFePO4 cells and PCB with optimized dimensions and adequate electrical performances as the customers require.
| Capacity | Rated Capacity :20Ah |
| Rated Voltage | 12.8V |
| Internal Resistant | ≤60mΩ |
| Discharge End Voltage | 9.6V |
| Charge Upper Limit Voltage | 14.6±0.2V |
| Standard Charge Circuit | 5 A |
| Fast Charge Circuit | 10 A |
|
Standard Discharge Circuit |
5 A |
| Fast Discharge Circuit | 10A |
| Discharge Circuit (max) | 20A |
| Weight1 | 2kg±0.1kg |
| Dimension(max) |
Length : 38mm Width : 133mm Height : 200mm
|
| Operational Temperature |
charge :0 ~ 45℃; discharge :-20 ~ 60℃ |
| Storage Temperature |
within a month : -5 ~ 35℃ within six months : 0 ~ 35℃ |
Looking for ideal 12V LFP Lithium Ion Battery Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the 12V Li-phosphate Battery High Discharge Rate are quality guaranteed. We are China Origin Factory of 12V LiFePO4 Deep DOD Rechargeable Accumulator. If you have any question, please feel free to contact us.
